BW Type 63 L cable gland brass

Name: BW Type 63 L cable gland brass
Brand: RK GLOBAL EXPORTER
Price: 1078.64 INR
Availability: InStock

Price 1078.64 INR/ Unit

Get a Price/Quote

MOQ : 10 Pieces

BW Type 63 L cable gland brass Specification

Locknut Included
Yes

Operating Condition
Indoor & Outdoor

Corrosion Resistant
High

Sealing Ring Present
Yes

Thread Standard
BS 6121

Earthing Mechanism
Integral

Installation
Panel Mountable

Suitable for Armour
Yes

Mechanical Retention
Excellent

Cable Entry Diameter
54-59 mm

BW Type 63 L cable gland brass Trade Information

Minimum Order Quantity
10 Pieces

Delivery Time
7 Days

About BW Type 63 L cable gland brass

Product Name: BW Type 63L Brass Cable Gland
Size: 63L
Type: BW Type (for armoured cables, indoor use)
Material: High-quality brass
Function: Secure termination and mechanical retention of armoured cables
Compression Type: Single compression (armour clamping)
Ingress Protection: IP65 / IP66 (typical for BW type)
Corrosion Resistance: Good resistance to moisture and industrial environments
Cable Type: Suitable for steel wire armoured (SWA) cables
Earth Continuity: Provides effective armour earthing
Finish: Natural brass / nickel plated (optional)
Applications: Electrical panels, indoor installations, industrial wiring
Standards: Industrial-grade, suitable for indoor use

Feature	Description
Premium Brass Construction	Offers high strength, corrosion resistance, and long service life.
Wide Size Range (165 to 90L)	Suitable for various cable diameters and industrial applications.
Available Thread Types	ET, NPT, and Metric (M) threads for international compatibility.
Strong Grip & Strain Relief	Ensures secure clamping of armored cables and prevents cable pull-out.
Suitable for Industrial Environments	Ideal for panels, machinery, switchgear, and outdoor electrical installations.

Secure and Versatile Cable Termination

With an armor-supporting structure, the BW Type 63 L cable gland delivers superior mechanical retention, making it perfect for heavy-duty electrical installations. Whether used indoors or exposed to the elements, its high corrosion resistance and robust sealing ring offer peace of mind and reliable operation for various environments.

Effortless Installation and Reliable Earthing

This gland features a panel-mountable design, integral earthing mechanism, and comes equipped with a locknut for straightforward assembly. It simplifies the installation process and ensures consistent earthing, significantly reducing downtime and enhancing operational efficiency.

FAQ's of BW Type 63 L cable gland brass:

Q: How is the BW Type 63 L cable gland installed for armored cable applications?

A: Installation is straightforward: Insert the cable through the gland and secure the armor underneath the brass cone. Attach the gland to the panel using the supplied locknut. The integral earthing mechanism ensures proper bonding, and the sealing ring provides added protection from environmental factors.

Q: What are the key benefits of using the BW Type 63 L cable gland in industrial environments?

A: This cable gland provides excellent mechanical retention, high corrosion resistance, and reliable earthing, making it highly suitable for demanding indoor and outdoor conditions. It also protects against dust and moisture, ensuring long-term cable safety and connection integrity.

Q: When should the BW Type 63 L cable gland be used over other cable glands?

A: It should be chosen when handling armored cables with entry diameters between 54-59 mm, especially in installations requiring high corrosion resistance and dependable mechanical retention for both indoor and outdoor environments.

Q: Where can I source the BW Type 63 L cable gland in India?

A: This cable gland is available from a wide network of distributors, exporters, importers, manufacturers, service providers, suppliers, and traders across India.

Q: What process ensures the BW Type 63 L's corrosion resistance?

A: The gland is manufactured from high-quality brass, which is naturally resistant to corrosion. Additionally, precision engineering and tight sealing with the included sealing ring further guard against environmental deterioration.

Q: How does the integral earthing mechanism benefit installations?

A: The built-in earthing mechanism ensures effective electrical continuity between the armored cable and the enclosure, improving overall safety and compliance with electrical standards.
