1/4" NPT(F)-1/4" OD SS304/SS316 Female Connector

Name: 1/4" NPT(F)-1/4" OD SS304/SS316 Female Connector
Brand: RK GLOBAL EXPORTER
Price: 150.0 INR
Availability: InStock

Price 150.0 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

1/4" NPT(F)-1/4" OD SS304/SS316 Female Connector Specification

Suitable Media
Gas, Oil, Water

Sealing Type
Metal-To-Metal

Installation
Threaded + Compression

Hex Size
Approx. 18 mm

Weight
Approx. 36 g

Non-magnetic
SS316 Option

Standards
ASME/ANSI B16.11

Wrench Tightening
Required

Connection End
Double Ferrule

Temperature Range
-20°C to 400°C

1/4" NPT(F)-1/4" OD SS304/SS316 Female Connector Trade Information

Minimum Order Quantity
10 Pieces

Delivery Time
7 Days

About 1/4" NPT(F)-1/4" OD SS304/SS316 Female Connector

Product Name: 1/4" NPT(F) 1/4" OD Female Connector
Connection Size:
Thread Side: 1/4" NPT (Female)
Tube Side: 1/4" OD
Material: SS 304 / SS 316 stainless steel
Function: Provides a secure and leak-proof connection between NPT male fittings and OD tubing
Construction Type: Precision-machined stainless steel connector for reliable sealing and long service life
Compatibility: Suitable for systems using 1/4" OD tubing and 1/4" NPT male threaded ports
Corrosion Resistance: Excellent resistance to rust, corrosion, and chemical attack (SS 316 recommended for harsh environments)
Applications: Instrumentation tubing, pneumatic & hydraulic systems, chemical processing, gas lines, water systems, and industrial pipelines
Finish: Smooth, precision-machined stainless steel surface
Standards: Industrial-grade fitting suitable for high-pressure and fluid handling applications

Feature	Description
SS 304 / SS 316 Stainless Steel	Ensures high strength, durability, and superior corrosion resistance.
Precision NPT Female Threads	Provides tight sealing and secure threaded connection.
Leak-Proof Performance	Designed to minimize leakage under pressure.
Wide Industrial Applications	Suitable for gas, fluid, pneumatic, and instrumentation systems.
Easy Installation	Simple and quick installation using standard tools.

Durable Construction with Wide Compatibility

Engineered with either SS304 or SS316 stainless steel, this connector stands up to corrosion and extreme temperatures. Its NPT female to 1/4" OD double ferrule design seamlessly integrates with standard pipes, supporting a range of media including gas, oil, and water. The product adheres to industry standard ASME/ANSI B16.11, ensuring interchangeability and safety.

Precision Sealing for Leak-Proof Joints

A robust metal-to-metal sealing mechanism eliminates the need for additional gaskets, and the double ferrule connection ensures proper compression. Wrench tightening is required during installation, making the assembly process straightforward while maximizing joint integrity. This ensures long-term, maintenance-free service in critical applications.

FAQ's of 1/4" NPT(F)-1/4" OD SS304/SS316 Female Connector:

Q: How is the 1/4" NPT(F)-1/4" OD SS304/SS316 female connector installed?

A: Installation involves threading the NPT(F) end into the corresponding male port and securing the 1/4" OD tube using the double ferrule compression fitting. Wrench tightening is necessary to achieve a secure, leak-proof connection.

Q: What are the advantages of using SS316 for this connector?

A: SS316 offers superior corrosion resistance and non-magnetic properties, making it ideal for harsh or high-purity environments where magnetic interference or aggressive media may be present.

Q: Where can this connector be used?

A: This connector is suitable for installations involving gas, oil, or water pipelines in industries such as chemical processing, instrumentation, and power plants, especially where reliable sealing and temperature tolerance are critical.

Q: When should I choose a metal-to-metal sealing connector?

A: Metal-to-metal sealing is recommended for high-temperature, high-pressure, or chemically aggressive environments where elastomeric seals may fail or degrade over time.

Q: What industry standards does this connector comply with?

A: It is manufactured in compliance with ASME/ANSI B16.11 standards, ensuring quality, performance, and compatibility with other standardized piping components.

Q: How does the double ferrule compression end benefit the user?

A: The double ferrule system enhances sealing capability and provides superior resistance to vibration and thermal cycling, ensuring durability and leak-free operation.
