1/8" NPT(M)-1/4" OD SS304/SS316 Male Connector

Name: 1/8" NPT(M)-1/4" OD SS304/SS316 Male Connector
Brand: RK GLOBAL EXPORTER
Price: 150.0 INR
Availability: InStock

Price 150.0 INR/ Unit

Get a Price/Quote

MOQ : 10 Pieces

1/8" NPT(M)-1/4" OD SS304/SS316 Male Connector Specification

Temperature Range
-40°C to 250°C

Torque Rating
Recommended 12-14 Nm

Standards
ASTM A276

Wrench Size
9/16 inch

Installation
Easy Swivel Nut

Sealing
Double Ferrule

Finish Color
Silver

Weight
Approx. 23 grams

Packing
Individual Poly Pack

Hex Body Length
Approx. 22 mm

1/8" NPT(M)-1/4" OD SS304/SS316 Male Connector Trade Information

Minimum Order Quantity
10 Pieces

Delivery Time
7 Days

About 1/8" NPT(M)-1/4" OD SS304/SS316 Male Connector

Product Name: 1/8" NPT(M) 1/4" OD Male Connector
Connection Size:
Thread Side: 1/8" NPT (Male)
Tube Side: 1/4" OD
Material: SS 304 / SS 316 stainless steel
Function: Provides a secure and leak-proof transition between NPT threaded ports and OD tubing
Construction Type: Precision-machined stainless steel connector for reliable sealing and long service life
Compatibility: Suitable for systems using 1/4" OD tubing and 1/8" NPT female threaded ports
Corrosion Resistance: Excellent resistance to rust, corrosion, and chemical attack (SS 316 recommended for aggressive environments)
Applications: Instrumentation tubing, pneumatic systems, hydraulic lines, chemical processing, gas lines, water systems, and industrial pipelines
Finish: Smooth, precision-machined stainless steel surface
Standards: Industrial-grade fitting suitable for high-pressure and fluid handling applications

Feature	Description
SS 304 / SS 316 Stainless Steel	Ensures high strength, durability, and superior corrosion resistance.
Precision NPT Male Threads	Provides tight sealing and secure threaded connection.
Leak-Proof Performance	Designed to minimize leakage under pressure.
Wide Industrial Applications	Ideal for gas, fluid, pneumatic, and instrumentation systems.
Easy Installation	Quick and simple installation using standard tools.

Precision Engineering for Reliable Connections

Manufactured under ASTM A276 standards, this connector offers robust performance in demanding environments. Whether for laboratory, industrial, or process automation setups, its silver finish and corrosion resistance ensure longevity and consistent results.

Effortless Installation for Practitioners

The easy swivel nut design and 9/16-inch wrench compatibility make on-site assembly simple and efficient. Its compact, lightweight build enhances maneuverability during installation, minimizing labor and downtime for both maintenance and new setups.

FAQ's of 1/8" NPT(M)-1/4" OD SS304/SS316 Male Connector:

Q: How is the 1/8" NPT(M)-1/4" OD SS304/SS316 Male Connector installed?

A: Installation is straightforward; use a 9/16-inch wrench to tighten the connector with the easy swivel nut design. Apply the recommended torque of 12-14 Nm to ensure a secure, leak-proof connection.

Q: What are the benefits of using a double ferrule sealing system in this connector?

A: The double ferrule system provides superior sealing by creating a firm grip on the tubing, minimizing the risk of leaks and enhancing the overall reliability of the connection.

Q: When should I choose SS304 versus SS316 material for this connector?

A: SS304 is suitable for general, non-corrosive environments, while SS316 offers improved corrosion resistance, making it optimal for marine, chemical, or harsher industrial settings.

Q: Where can I purchase or order this connector in India?

A: This connector is available through distributors, exporters, importers, manufacturers, service providers, suppliers, and traders throughout India. Each unit is individually poly packed for quality assurance.

Q: What is the typical process for installing this connector in a fluid or gas system?

A: First, prepare the tubing and fittings. Slide the nut and ferrules onto the tubing, insert the tube into the connector body, and tighten the nut using a 9/16-inch wrench to the recommended torque for a secure fit.

Q: How does the temperature range impact the connector's usage?

A: With a temperature tolerance of -40C to 250C, the connector is suitable for a wide range of applications, including both low and high-temperature processes, ensuring safety and reliability in various operational environments.

Q: What are the main usage scenarios for this connector?

A: It is extensively used in fluid handling, instrumentation, and process control systems where durable, leak-proof, and high-temperature connections are essential.
