The
Industrial Welding Neck Flanges consists of a circular fitting with a protruding rim around the circumference and the offered flange is broadly used for connecting tubes, vacuum pumps, and vacuum chambers. Offered flanges are designed with the aid of sophisticated technology under the strict guidance of skilled professionals at the vendors end keeping in mind the set quality norms. Further, offered
Industrial Welding Neck Flanges are recognized for their unique features like durable finish standards, easy installation, ruggedness, and dimensional accuracy.
Specifications :
- N.Bore:A:B:C:D:F:J:L:P:T:Holes
- 15:89:11.1:1.6:35:30:21.3:48:60.3:15.9:4
- 20:98:12.7:1.6:43:38:26.7:52:69.8:15.9:4
- 25:108:14.3:1.6:51:49:33.4:56:79.4:15.9:4
- 32:117:15.9:1.6:64:59:42.2:57:88.9:15.9:4
- 40:127:17.5:1.6:73:65:48.3:62:98.4:15.9:4
- 50:152:19:1.6:92:78:60.3:64:120.6:19:4
- 65:178:22.2:1.6:105:90:73:70:139.7:19:4
- 80:190:23.8:1.6:127:108:88.9:70:152.4:19:4
- 90:216:23.8:1.6:140:122:101.6:71:177.8:19:8
- 100:229:23.8:1.6:157:135:114.3:76:190.5:19:8
- 125:254:23.8:1.6:186:164:141.3:89:215.9:22.2:8
- 150:279:25.4:1.6:216:192:168.3:89:241.3:22.2:8
- 200:343:28:1.6:270:246:219.1:102:288.4:22.2:8
- 250:406:30.2:1.6:324:305:273:102:362:25.4:12
- 300:483:34.8:1.6:381:365:323.9:114:431.8:25.4:12
- N.Bore:A:B:C:D:F:J:L:P:T:Holes
- 15:95:14.3:1.6:35:38:21.3:52:66.7:15.9:4
- 20:117:15.9:1.6:43:48:26.7:57:82.6:19:4
- 25:124:17.5:1.6:51:54:33.4:62:88.9:19:4
- 32:133:19:1.6:64:64:42.2:65:98.4:19:4
- 40:156:20.6:1.6:73:70:48.3:68:114.3:22.2:4
- 50:165:22.2:1.6:92:84:60.3:70:127:19:8
- 65:190:25.4:1.6:105:100:73:76:149.2:22.2:8
- 80:210:28.6:1.6:127:117:88.9:79:168.3:22.2:8
- 90:229:30.2:1.6:140:133:101.6:81:184.2:22.2:8
- 100:254:31.8:1.6:157:146:114.3:86:200.2:22.2:8
- 125:279:34.9:1.6:186:178:141.3:98:235:22.2:8
- 150:318:36.8:1.6:216:206:168.3:98:269.9:22.2:12
- 200:381:41.3:1.6:270:260:219.1:111:330.2:25.4:12
- 250:444:47.6:1.6:324:321:273:117:387.4:28.6:16
300:521:50.8:1.6:381:375:323.9:130:450.8:31.8:16
